|Journal of Integer Sequences, Vol. 3 (2000), Article 00.1.1|
Abstract: Consider lattice paths in the plane allowing the steps (1,1), (1,-1), and (w,0), for some nonnegative integer w. For n > 1, let E(n,0) denote the set of paths from (0,0) to (n,0) running strictly above the x-axis except initially and finally. Generating functions are given for sums of moments of the ordinates of the lattice points on the paths in E(n,0). In particular, recurrencess are derived for the cardinality, the sum of the first moments (essentially the area), and the sum of the second moments for paths in E(n,0). These recurrences unify known results for w= 0, 1, 2, i.e. those for the Dyck (or Catalan), Motzkin, and Schröder paths, respectively. The sum of the second moments is seen to equal the number of unrestricted paths running from (0,0) to (0,n-2).
1. Introduction: The paths and their moments
2. The recurrences
3. Enumerating restricted paths
4. Factorial moments
5. Area and second moments
6. Relating second moments to central numbers
8. Related studies
Let w be a fixed nonnegative integer. We will consider those lattice paths in the Cartesian plane whose permitted step types are the up diagonal step (1,1) denoted by U, the down diagonal step (1,-1) denoted by D, and the horizontal step (w,0) denoted by H. When w= 0, only U-steps and D-steps are permitted. We weight the steps by assigning 1 to each U-step, 1 to each D-step, and an indeterminate t to each H-step. The t-weight of a path P, denoted by |P|, is the product of the weights of its steps; and the t-weight of a set of paths S, denoted by |S|, is the sum of the t-weights of the paths in S.
Often we will suppress the parameter w and the indeterminate t in our notation. Let U(x,y) denote the set of all unrestricted lattice paths using the permitted step types and running from (0,0) to (x,y). We define the set of generalized Motzkin paths, denoted by M(x,y), to be the set of paths in U(x,y) that never run below the x-axis except initially and perhaps finally. Of particular interest is the set of elevated paths, denoted by E(x,y), consisting of those paths in M(x,y) that never touch the x-axis except initially and perhaps finally. For an example, see Figure 1 and the left column of Table 1 which give the four paths in E(5,0) when w = 1.
Let fn(w) denote |E(n,0) | for n >= 2, with f0(w) = f1(w) = 0. For t = 1, there are three classical sequences covered by this notation, specifically for w = 0, 1 or 2. When w = 0, there are no horizontal steps and the paths of E(n,0) are the so-called elevated Dyck (or Catalan) paths; the corresponding sequence (fn(0))n >= 2 = (1, 0, 1, 0, 2, 0, 5, 0, 14, . . . ) is the sequence of (aerated) Catalan numbers. For w = 1 and t = 1, (fn(1))n >= 2 is the sequence of Motzkin numbers. For w = 2 and t = 1, (fn(2))n >= 2 is the sequence of (aerated) large Schröder numbers. See Table 2 in Section 7. In 1948, using different indexing, Motzkin  introduced the sequence (fn(1))n >= 2, where fn(1) denotes the number of ways to join n-2 points on a circle by nonintersecting chords. Donaghey and Shapiro  made an early study of this sequence which included lattice paths equivalent to those of M(n,0) with w= 1.
path P in E(n,0) as a rectilinear curve. Let
(0, P(0)), (1, P(1)), ..., (n, P(n)) be the list of
points (points with integer coordinates)
on the path P. We will refer to the values
P(0), P(1), P(2), ..., P(n) as
the path ordinates of P. Define
the rth moment of P to be
|to f5(1)||to g5(1)||to total area||to h5(1)|
Table 1: This table gives the contributions
f5(1) = 3t+t3,
g5(1) = 4t+t3,
h5(1) = 6t+t3, and the total area by the
the four paths
of E(5,0) for w = 1.
For fixed w >= 0 and for n >= 2, we define the following sums of
t-weighted moments for the path set E(n,0):
The main results of this paper are the three recurrences for these sequences, given uniformly in equations (5), (6), and (7), and the generating function for the factorial moments given in Proposition 5. In Section 2 we state these recurrences, which we then establsh by generating function methods in Sections 3, 4, and 5. In Section 6 we prove a surprising result relating second moments to central unrestricted numbers. In Section 7 we will give some examples of these sequences.
For any w >= 0, consider the following unified set of
for the sequences,
(fn)n >= 2,
(gn)n >= 2, and
(hn)n >= 2, which we have defined above
in terms of t-weighted elevated
|n fn||=||4(n-3) fn-2 + (2n - 3 w ) t fn-w - (n - 3 w ) t2 fn-2w,||(5)|
|(n-1)gn||=||4(n-3) gn-2 + (2n - 2w-2)tgn-w - (n - 2 w-1)t2 gn-2w,||(6)|
|(n-2)hn||=||4(n-3) hn-2 + (2n - w - 4 )thn-w - (n - w - 2)t2 hn-2w.||(7)|
For w = 0,
(fn(0))n >= 2,
(gn(0))n >= 2, and
(hn(0))n >= 2 satisfy
|n fn(0)||=||4(n-3) fn-2(0)||(8)|
|(n-1) gn(0)||=||4(n-3) gn-2(0)||(9)|
|(n-2) hn(0)||=||4(n-3) hn-2(0)||(10)|
The proof of this Proposition is covered by the proofs of Propositions 2, 3, and 4. Recurrence (8) dates from about 1758, when Euler  recorded it, slightly re-indexed, when he and Segner  were considering counting triangulations of convex polygons. See Section 8. It follows immediately that, for k >= 0,
For w >= 1, we have the following more general result, which in proved in the next section:
With an = an(w) denoting the t-weighted area, , the trapezoidal area formula shows that an = (n-1)gn for all n >= 2. The following result, proved in Section 5, generalizes one of Kreweras  for w = 2 and t = 1.
We remark that (10) is a well-known recurrence for the central binomial coefficients. In the case when w = 1 with t = 1, recurrence (7) dates from 1764, as Euler  proved that the central trinomial coefficients satisfy this recurrence when appropriately re-indexed. Our knowledge that these central coefficients are solutions to the recurrences (7) and (10) led to an interesting relationship between second moments and central numbers of the form |U(n,0)| for arbitrary w. Specifically, in Section 6 we will see that |U(n-2, 0 )| satisfies a recurrence that is also satisfied by hn(t); thus we have a proof of identity (13) below. The proof of the first part of the following appears in Section 5.
Consider the generating function
the exception of the point path, each path in
M(n,0) either begins with an H-step
or immediately leaves the x-axis and then later returns
for a first time.
Consequently, with L denoting
juxtaposition indicating concatenation,
we have a decomposition
that defines L recursively:
Note that the coefficient of
zn both in
series for F(z) and in the power series for
For n >= 2,
With M denoting M(z), we
claim that the
following string of equations holds:
To establish this string we first
each path in E(j,k) must depart from each line y = c,
for integer c,
0 <= c < k,
for a last time.
Hence a simple convolution argument shows
that the generating function for m(j,k) satisfies
Setting r = 1 in
Proposition 5, we obtain a
generating function for sums of the t-weighted areas:
There is an interesting corollary when w = 1. Using
partial fractions decomposition, the generating function
To obtain the generating function for the second moments,
the following, where the constant of integration is checked to be
From (22), differentiation with respect to z yields
Let u(x,y) denote |U(x,y)|.
Since any path to the point (n+1,k) must end with a U, D, or H step,
|2fn+2||=||2u(n,0) - 2u(n,2)|
|=||4 u(n,0) - 2u(n+1,1) +2 t u(n-w+1,1)|
|=||4 u(n,0) + t u(n-w+2,0)- u(n+2,0) - (t2u(n-2w+2,0)-t u(n-w+2,0))|
|=||-u(n+2,0) + 4 u(n,0) + 2 t u(n-w+2,0) -t2 u(n-2w+2,0).||(25)|
The first formula of (11) yields the following known
the Catalan numbers and the central binomial numbers.
Upon replacing 2k+2 by n in that formula, we find for
h = 0, n >= 2 and n even,
In Table 2, we record the previously studied, and named, examples satisfying the recurrences in Propositions 1 to 4, along with their reference number from Sloane's On-Line Encyclopedia of Integer Sequences . These examples correspond to sets of elevated paths, (E(n,0) )n >= 2, so in the table n = 2, 3, 4 . . . and k = 1, 2, 3 . . . .
|1||fn(0)||1, 0, 1, 0, 2, 0, 5, 0, 14, 0, 42||aerated Catalan nos.|
|1||f2k(0)||1, 1, 2, 5, 14, 42, 132, 429, 1430, 4862||Catalan nos.||A000108|
|1||a2k(0)||1, 4, 16, 64, 256, 1024, 4096, 16384||powers of 4||A000302|
|1||h2k(0)||1, 2, 6, 20, 70, 252, 924, 3432, 12870||central binomial nos.||A000984|
|1||fn(1 )||1, 1, 2, 4, 9, 21, 51, 127, 323, 835, 2188||Motzkin nos.||A001006|
|2||fn(1 )||1, 2, 5, 14, 42, 132, 429, 1430, 4862||(lacking initial 1)||A000108|
|3||fn(1 )||1, 3, 10, 36, 137, 543, 2219, 9285, 39587||(tree-like polyhexes)||A002212|
|4||fn(1 )||1, 4, 17, 76, 354, 1704, 8421, 42508||(walks on cubic lattice)||A005572|
|1||an(1)||1, 2, 7, 20, 61, 182, 547, 1640, 4921||A014983|
|1||hn(1 )||1, 1, 3, 7, 19, 51, 141, 393, 1107, 3139||central trinomial nos.||A002426|
|1||f2k(2)||1, 2, 6, 22, 90, 394, 1806, 8558, 41586||large Schröder||A006318|
|a2k(2)||1, 7, 41, 239, 1393, 8119, 47321, 275807||A002315|
|1||h2k(2)||1, 3, 13, 63, 321, 1683, 8989, 48639||central Delannoy nos.||A001850|
|1||fn(3 )||1, 0, 1, 1, 2, 3, 6, 10, 20, 36, 72, 136||A005418|
|1||an(3)||1, 0, 4, 4, 16, 24, 71, 128, 328, 650||A053441|
|1||hn(3 )||1, 0, 2, 1, 6, 6, 21, 30, 82, 141, 342, 650||A053442|
In Table 2, the ``walks on cubic lattice'' entry illustrates one role played by the indeterminate t. Corresponding to the case w = 1 and t = 4, Guy  found fn (mildly re-indexed) to count the walks on a three-dimensional lattice that use unit steps in all six standard directions (i.e. the positive and negative unit steps parallel to the three axes), that start at (0,0,0), end on the x-y plane, and never pass beneath that plane. More generally, for m > 3, w = 1 and t = 2m-1, we find that fn counts the walks of length n-2 on the m-dimensional integer lattice that use the unit steps in all 2m standard directions, start at the origin, end on the hyperplane, x1 + ... +xm-1 = 0, and never pass through a lattice point (x1, ... , xm) for which xm < 0. To see this we identify the unit step in the positive xm direction with the U-step, the unit step in the negative xm direction with the D-step, and the set of the other 2m-1 steps, none of which affects the distance from the hyperplane, x1 + ... +xm-1 = 0, with a weighed H-step.
Another example utilizing t is the enumeration of the horizontal
steps over all paths in E(n,0). Let fn,k denote the number of
E(n,0) having k horizontal steps. We find that the
generating function for the total
horizontal steps on paths having k horizontal steps satisfies
As noted in , in the 1730's, Ming An-tu, a Mongolian mathematician, was aware of the Catalan numbers, (cn)n>=0 = (1, 1, 2, 5, 14, ...), in a non-combinatorial sitting. He discovered several recurrence for these numbers including the well-known convolution recurrence, cn = c0cn-1 + c1cn-2 + . . . + cn-1c0. In about 1758, Euler  and Segner  made the first European discovery of these numbers while counting the triangulations of a convex polygon. They observed that cn-2 is the number of ways to draw non-crossing diagonals between the vertices of a convex n-gon. Segner recorded and proved the above convolution recurrence in terms of triangulations of polygons. Euler observed, without giving a proof, that cn = (4n-2)/(n+1) cn-1, which is essentially (8), and then gave a closed form for cn as a product of ratios that reduces to a ratio of product as in the first formula of (11).
There are several studies on lattice paths, in addition to those mentioned previously, that have influenced our results. Barcucci, Pinzani, and Sprugnoli  have made a systematic analysis containing recurrences - many mixed - for the Motzkin paths, i.e. w = 1 and t = 1, involving the sequences for count, central entries (central trinomial coefficients), and other related statistics. Recently the author  has established (5), (6), and (7) bijectively for Motzkin paths.
Besides Kreweras , Bonin, Shapiro, and Simion  have considered elevated Schröder paths and the recurrence (12) for w = 2. For w = 2 the author  has employed bijective schema to establish recurrences (5) and (12); in  he has considered (5), (6), and (7) in terms of parallelogram polyominoes. Most recently for w = 2, Merlini, Sprugnoli, and Verri  have given additional proofs for (5) with essentially an arbitrary t, while Pergola and Pinzani  have developed an encoding relating area to path count to obtain (12) bijectively.
Merlini, Sprugnoli, and Verri  have developed generating functions for the total area bounded by lattice paths where the permitted steps are more general than our U, D, and H. For Dyck paths, Chapman  has considered the generating functions for the sums of path moments and the relationship between the generating functions for elevated versus non-elevated paths.
Stanley  has given an extensive treatment of generalizations of the central entries, |U(n,0)|, under the name ``diagonals''. In  his results for differentiably finite power series relate to our use of the generating functions and of Sections 3 and 5. Correspondingly, he considered polynomially recursive sequences, for which our sequences (fn), (gn), and (hn) are prime examples.
Acknowledgements: The author thanks Lou Shapiro for sharing an early draft of  and for his suggestions improving this paper. The author also thanks Joyce Sulanke for her assistance in translating , , and .
(This paper uses lattice paths to produce a unified treatment of sequences A000108, A000302, A000984, A001006, A001850, A002212, A002315, A002426, A005418, A005572, A006318, A014983, A053441, A053442 in the On-Line Encyclopedia of Integer Sequences.)
